CSS / Reference / background-image: Images, Gradients, Relative Paths, and Layers

background-image paints an image or gradient behind an element. A background has no image alternative text, so use an img with appropriate alt when the picture conveys essential information.

Syntax and value choices

Property Initial value Inherited Main application conditions
background-image none No All elements; visible effects depend on the text, image, or box conditions below

Initial values are not necessarily the values assigned to HTML elements by the browser’s stylesheet. Inspect the actual result in developer tools’ Computed panel.

.hero { background-image: url("images/scene.webp"); }
.card { background-image: linear-gradient(135deg, #006c9c, #bfe3ff); }
Value or category Behavior and choice
none No background image.
url(...) Load an image from the specified address.
linear-gradient(...) Create a gradient image in CSS.
image1, image2 Paint the first listed layer above subsequent layers.

For supported values and conditions, see MDN background-image.

Run the example and compare results

Save this complete code as css-reference-10590-example.html in UTF-8 and open it in a browser. Keep its demonstration styles in that file rather than pasting them into a site-wide stylesheet.

<!doctype html>
<html lang="en">
<head>
<meta charset="utf-8">
<meta name="viewport" content="width=device-width, initial-scale=1">
<title>background-image comparison example</title>
<style>
body { margin: 0; color: #20242b; background: #fff; font: 16px/1.7 "Malgun Gothic", sans-serif; }
#demo { padding: 24px; max-width: 820px; margin: auto; }
h1 { font-size: 22px; margin: 0 0 20px; }
.samples { display: flex; flex-wrap: wrap; gap: 24px; }
.label { margin: 0 0 8px; font-weight: 700; }
.target, .reference { width: 240px; height: 140px; border: 1px solid #718096; }
.target { background-image: linear-gradient(135deg, #006c9c, #bfe3ff); }
</style>
</head>
<body>
<main id="demo">
<h1>background-image comparison</h1>
<section class="samples"><div class="a"><p class="label">Gradient</p><div class="target"></div></div><div class="b"><p class="label">SVG background</p><div class="reference"></div></div></section>
</main>
</body>
</html>

The first box uses a gradient and the second uses an SVG built into the example. No external image file is needed for this complete exercise.

background-image browser comparison showing the specified and reference values in the same example

File references and layer order

A relative image URL in an external stylesheet normally resolves from the stylesheet’s location, not the HTML file’s folder. The first listed image is the top layer; background color is underneath all image layers.

An image does not create the box height

An empty element still needs size from content, padding, height, or an appropriate aspect ratio. Use no-repeat when tiling is unwanted, then choose position and size independently.

Change one setting at a time

Use the complete example file above. Change only the specified selector or value rather than several comparison conditions at once.

  1. An external CSS image path resolves from that stylesheet. With site/index.html, site/css/style.css, and site/images/scene.webp, use ../images/scene.webp in style.css.
  2. Combine the gradient and SVG as two layers, then reverse only their order. For a file exercise, supply a real file and inspect its resolved request and response in Network.

Replace the original .target background-image declaration with this rule. The translucent gradient paints above the SVG. Reverse only the two image values to put SVG on top and compare overlap; restore the original single gradient afterward. A later background shorthand can reset image, repeat, position, size, origin, clip, attachment, and color.

.target {
  background-image: linear-gradient(135deg, rgb(255 209 102 / 50%), transparent),
}

For combining background properties in one practical design, see CSS Background Colors and Images: cover and contain. Related properties to compare alongside these conditions are background-size, background-repeat.

When the result is missing or unexpected

  • Inspect the resolved request URL and response in Network.
  • Check the element’s dimensions if a correctly loaded background remains invisible.
