CSS / Reference / aspect-ratio: Preferred Ratios, Natural Images, and Constraints
aspect-ratio supplies a preferred width-to-height ratio used in automatic sizing. Setting both dimensions explicitly, or other min/max and layout constraints, can take precedence over that preferred ratio.
Syntax and value choices
| Property | Initial value | Inherited | Main application conditions |
|---|---|---|---|
aspect-ratio |
auto | No | Most sizing boxes; excludes ordinary inline and internal table boxes |
Initial values are not necessarily the values assigned to HTML elements by the browser’s stylesheet. Inspect the actual result in developer tools’ Computed panel.
.video { width: 100%; aspect-ratio: 16 / 9; }
.square { width: 240px; aspect-ratio: 1; }
| Value or category | Behavior and choice |
|---|---|
auto |
Use no specified ratio; a replaced element may have a natural ratio. |
16 / 9 |
Prefer a width-to-height ratio of 16 to 9. |
1 |
Prefer a square. |
auto 16 / 9 |
Use a natural replaced-element ratio when available; otherwise use the specified ratio. |
For supported values and conditions, see MDN aspect-ratio.
Run the example and compare results
Save this complete code as css-reference-13776-example.html in UTF-8 and open it in a browser. Keep its demonstration styles in that file rather than pasting them into a site-wide stylesheet.
<!doctype html>
<html lang="en">
<head>
<meta charset="utf-8">
<meta name="viewport" content="width=device-width, initial-scale=1">
<title>aspect-ratio comparison example</title>
<style>
body { margin: 0; color: #20242b; background: #fff; font: 16px/1.7 "Malgun Gothic", sans-serif; }
#demo { padding: 24px; max-width: 820px; margin: auto; }
h1 { font-size: 22px; margin: 0 0 20px; }
.samples { display: flex; flex-wrap: wrap; gap: 24px; }
.label { margin: 0 0 8px; font-weight: 700; }
.target, .reference { width: 240px; height: auto; background: #bfe3ff; }
.target { aspect-ratio: 16 / 9; }
.reference { aspect-ratio: 1; }
</style>
</head>
<body>
<main id="demo">
<h1>aspect-ratio comparison</h1>
<section class="samples"><div class="a"><p class="label">16 / 9</p><div class="target"></div></div><div class="b"><p class="label">1</p><div class="reference"></div></div></section>
</main>
</body>
</html>
At 240px width, the 16:9 box is 135px high and the square is 240px high. An auto height can change with the width.
A preference rather than a locked size
Width, height, min/max limits, content minimums, and flex or grid constraints influence the final box. A ratio declaration does not rewrite two fixed dimensions to force a match.
Image boxes versus image content
Object-fit determines how an image is placed inside its box: cover can crop and contain can leave space. Natural HTML dimensions and a CSS preferred ratio have different roles. Keep loading placeholders and the final image behavior intentional.
Intrinsic image ratios and preferred CSS ratios
Save this complete document as css-reference-13776-practice.html in UTF-8 and open it in a browser. Test it as a separate file rather than nesting it inside another example.
<!doctype html>
<html lang="en">
<head>
<meta charset="utf-8">
<meta name="viewport" content="width=device-width, initial-scale=1">
<title>Intrinsic image ratios and preferred CSS ratios</title>
<style>
body { margin: 16px; color: #20242b; font: 16px/1.7 sans-serif; }
main { max-width: 52rem; margin: auto; }
h1 { font-size: 1.35rem; }
.samples { display: flex; flex-wrap: wrap; gap: 24px; }
.samples > * { max-width: 100%; min-width: 0; }
:focus-visible { outline: 3px solid #005fcc; outline-offset: 3px; }
.sample {width:240px;max-width:100%;background:#e6f2ff;border:0;} img {display:block;height:auto;} .auto {aspect-ratio:auto 16 / 9;} .crop {aspect-ratio:16 / 9;height:auto;object-fit:cover;} .contain {object-fit:contain;}
</style>
</head>
<body>
<main>
<h1>Intrinsic image ratios and preferred CSS ratios</h1>
</main>
</body>
</html>
At 240px wide, the ordinary div is 135px tall; the loaded 2:1 image is 120px because auto uses its natural ratio. Without auto, the 16/9 image box is 135px: cover crops and contain leaves space. Change only .sample width to 200px, inspect proportional changes, and restore it. A preferred ratio does not forcibly override two definite dimensions.
In the separate ratio example, adding height:100px to .sample makes both dimensions definite at 240×100px; the preferred ratio does not override them. Restore it, then add only min-height:160px to observe the minimum constraint exceeding 135px. Test each constraint separately and remove it to restore the original.
For responsive image sizing and ratios, see Responsive Images and Video: aspect-ratio and object-fit. Related properties to compare alongside these conditions are box-sizing.
When the result is missing or unexpected
- Inspect height:auto and min/max constraints when the ratio appears wrong.
- Inspect object-fit and the box dimensions if a photo is distorted.
